Strengths of the Aero-Basic
Guaranteed work and operator safety thanks to the generously dimensioned vacuum reservoir with an intelligent warning device
No downtime thanks to the integrated motor protection switch, which protects the vacuum generator from winding damage.
Maximum durability thanks to robust welded steel construction of frame and hot-dip galvanised crossbars.
Short set-up times for different transport good dimensions because of suction plates that can be individually locked in place using manual slide valves (already included in the basic package)
Damage-free and gentle transportation due to the outstanding-quality full elastomer seals with an extremely long service life
Low operating costs thanks to the energy-efficient vacuum generator and optional pump control module, which perfectly regulates the activity of the vacuum generator.
Unique versatility of the modular basic system, which can be individually expanded with additional options
Quick and easy maintenance: The intelligent suction plate concept enables worn suction seals to be replaced in seconds with virtually no tools.
Product variants
The AERO-BASIC vacuum lifter is available in different versions with:
- load capacities from 150 to 2,000 kg
- 4 to 10 suction plates
- 2 to 5 cross beams
- different suction plate diameters, cross beam lengths, handle lengths, suspension eyes, etc.
We will be happy to advise you on the selection of the right device for your application.
Optional configuration / accessories
ECOMATIC & SAFETY
A clearly visible red and green LED light indicate that the vacuum lifter is ready for use.
The Ecomatic pump control module regulates the activity level of the vacuum pump. Depending on the frequency and use of the appliance, power consumption can be reduced by up to 70%.
Park & Move
Support feet mounted directly on the appliance. The height can be varied via a locking pin. Castors are also provided for transporting the system.
Article code suffix: -PR
Stacking
This module consists of an operating handle that can be adjusted to the operator's position or working height using a Bowden cable. The operating handle can be angled in various stages halfway along its length.
(bei Tragfähigkeiten über 600 kg auf Anfrage)
Chain hoist connection
As an option, the vacuum lifting device can be configured with a spiral cable and a Harting plug instead of a CEE plug. This enables the vacuum lifter to be powered directly at the chain hoist and prevents cables from getting in the way in the work area.
Article code suffix: -CH
Hydro
A water separator protects the vacuum pump from moisture and dirt.
Article code suffix: -HY
3.0-metre main cross beam
Extension of the main cross beam to 3.0 m to compensate for the overhang at both ends when lifting extra-large sized sheet meta
Holder bag for crane control bulb
Adaptation option for the crane control bulb on the device
Cable drum 5 m
Optional cable drum (5 m) for indoor use
Cable drum 10 m
Optional cable drum (10 m) for indoor use
